Drawer-Type Permanent Magnetic Separator | High-Gauss Maintenance-Free Dry Iron Remover for Lithium, Ceramic & Food Industries
Core Advantages
✅
High-Intensity & Efficient Iron Removal for Versatile Industries
Built with high-performance permanent magnets, it delivers magnetic field strength from 6,000 to 16,000 Gauss, effectively capturing micro ferrous impurities in dry powder, flake, and granular materials. It is widely used in lithium battery cathode/anode materials (lithium carbonate, lithium hydroxide, lithium iron phosphate, ternary precursors, etc.), ceramics, chemicals, plastics, mining, and food industries, significantly improving material purity.
✅
Power-Free Operation with Long-Term Stability & Energy Savings
Working entirely on permanent magnetism, it requires no external power supply, eliminating excitation current and temperature rise issues to reduce energy costs. With a demagnetization rate of ≤5% over 3 years, the magnetic field remains stable, unaffected by power outages or temperature changes, ensuring safe and reliable long-term operation.
✅
Temperature & Corrosion Resistance for Harsh Conditions
Operating temperature ranges from 60℃ to 350℃. Optional ETFE/PTFE/nano-ceramic coatings enhance wear and corrosion resistance, enabling stable performance in humid, dusty, and other harsh environments with a long service life.
✅
Full Range of Sizes & Customizable Design
Standard DN150~DN300 models are available, with customizable layers, bar quantities, and dimensions to fit different pipeline and production line requirements. The simple structure minimizes downtime and maintenance costs.
✅
High Adaptability with Easy Installation & Low Maintenance
Simple design allows quick installation. Models can be selected based on material characteristics and iron removal requirements. Routine maintenance only requires cleaning impurities from the magnetic bars, reducing labor and downtime costs significantly.
Product Parameters
| Item |
Specification |
| Product Name |
Drawer-Type Permanent Magnetic Separator |
| Applicable Materials |
Dry powder, flake, and granular materials |
| Typical Industries |
Lithium battery materials, ceramics, chemicals, plastics, mining, food, etc. |
| Magnetic Field Strength |
6,000–16,000 Gauss (customizable by model) |
| Operating Temperature |
60℃–350℃ |
| Demagnetization Rate |
≤5% over 3 years |
| Optional Coatings |
ETFE / PTFE / Nano-ceramic coating |
| Standard Sizes |
DN150, DN200, DN250, DN300 |
| Optional Layers |
3 layers, 4 layers, 6 layers (customizable) |
| Magnetic Bar Quantity |
7–33 bars (configured by size and layers) |
| Housing Material |
Stainless steel / Carbon steel (customizable) |
Q&A
Q1: What is the working principle of this separator?
A1: It uses the high magnetic field generated by permanent magnets. When dry materials with magnetic impurities pass through, the impurities are adsorbed on the magnetic bars by magnetic force, thus separating from the materials to achieve iron removal.
Q2: What are the magnetic strength and temperature resistance specifications?
A2: The standard magnetic field strength ranges from 6,000 to 16,000 Gauss, customizable based on impurity characteristics. The operating temperature range is 60℃–350℃, with special coatings available for high-temperature, humid, and dusty conditions.
Q3: Is the magnet durable? Is long-term performance guaranteed?
A3: Made of high-performance permanent magnets with a demagnetization rate of ≤5% over 3 years, the magnetic field remains stable. The robust structure and simple maintenance ensure a long service life with low operating costs.
Q4: How to choose the right size and number of layers?
A4: Choose based on pipeline size, material throughput, and required iron removal precision:
- DN150/DN200: Suitable for medium-small flow and low impurity content scenarios.
- DN250/DN300: Suitable for large flow and high impurity content scenarios.
- More layers mean more magnetic bars and higher removal precision, available on request.
Q5: Is customization available? What maintenance is required?
A5: Full customization is available, including size, layers, bar quantity, and coating. Daily maintenance only requires pulling out the drawer and cleaning impurities from the magnetic bars, which is simple and requires no complex operations.
Closing
We specialize in the R&D and manufacturing of industrial permanent magnetic iron removal equipment. Our drawer-type permanent magnetic separator provides stable and efficient dry iron removal solutions for lithium, ceramic, and food industries with high magnetic strength, maintenance-free operation, and wide adaptability. Factory direct supply, customized services, and bulk order support are available. Welcome global buyers and engineering contractors to contact us for cooperation.
